Paris DC24 #0002
Sort of my very first guitar build from scratch, sort of not… I actually screwed up the body of this guitar initially, so I filled in the parts I messed up and painted the body to become #0003, also known as “Nick’s Guitar”!
DC24 = Double Cut, 24 fret
Specifications
| Body | |
|---|---|
| Construction | Solidbody |
| Back Wood | Mahogany |
| Top Wood | Maple |
| Top Wood Type | 1/4" Cap |
| Top Carve | Rounded Edge |
| Binding | - |
| Neck | |
|---|---|
| Number of Frets | 24 |
| Scale Length | 25.5" |
| Neck Wood | Flame Maple |
| Neck Construction | Single-Ply |
| Truss Rod | Dual Action |
| Neck Shape | Thick Shouldery Boi |
| Neck Width at the Nut | 42mm |
| Neck Width at the Heal | 56mm |
| Fretboard Wood | Ebony |
| Fretboard Radius | 20" |
| Fretboard Inlays | - |
| Headstock | KRVL 2+4 |
| Headstock Logo | - |
| Neck/Body Assembly | |
|---|---|
| Assembly Type | Bolt-on |
| Hardware | |
|---|---|
| Bridge | Chrome Hipshot |
| Tuners | Chrome Locking |
| Nut | Bone Nut |
| Electronics | |
|---|---|
| Bridge Pickup | Seymour Duncan JB |
| Neck Pickup | Seymour Duncan Jazz |
| Controls |
Volume - Push/Pull Coil Split Neck Pickup Tone - Push/Pull Coil Split Bridge Pickup 3-Way Toggle Switch |
| Other | |
|---|---|
| Strings | Elixir NonoWeb Medium 11-49 |
| Tuning | Eb |
