Tel Aviv T24F7 #0007
My first foray into building extended range guitars (and certainly not my last), this 7-string T-style beast was commissioned for a professional guitarist, and close friend of mine. Interestingly, while designed very much to a specification conducive to playing metal, this guitar was actually designed as a tool to aid in scoring and composition with an extra low string to handle more low end compared to a standard 6-string guitar. Obviously, it does metal too, though :)
T24X7 = T-model, 24 fret, 7 strings
Specifications
| Body | |
|---|---|
| Construction | Solidbody |
| Back Wood | Basswood |
| Top Wood | Torrefied Flame Maple |
| Top Wood Type | Cap |
| Top Carve | Arm Cut |
| Binding | Natural |
| Neck | |
|---|---|
| Number of Frets | 24 |
| Number of Strings | 7 |
| Scale Length | 26.5" |
| Neck Wood | Torrefied Flame Maple |
| Neck Construction | Single-Ply |
| Truss Rod | Dual Action |
| Neck Shape | Thin C |
| Neck Width at the Nut | ?mm |
| Neck Width at the Heal | ?mm |
| Fretboard Wood | Rosewood |
| Fretboard Radius | 16" |
| Fretboard Inlays | - |
| Headstock | KRVL 7-String |
| Neck/Body Assembly | |
|---|---|
| Assembly Type | Bolt-on |
| Hardware | |
|---|---|
| Bridge | Black Hipshot-style |
| Tuners | Black Locking |
| Nut | Bone Nut |
| Electronics | |
|---|---|
| Bridge Pickup | Bare Knuckle Aftermath 7 |
| Neck Pickup | Bare Knuckle Aftermath 7 |
| Controls |
Volume - Push/Pull Coil Split Neck Pickup Tone - Push/Pull Coil Split Bridge Pickup 3-Way Blade Switch |
| Other | |
|---|---|
| Strings | Elixir NonoWeb 7-String |
| Tuning | Drop A |
